4 tons gas fired boiler export price

To know the export price of 4 tons of gas-fired boilers, first of all, we need to know the type of gas-fired boilers and the price of boilers, then the price of burners, valves and the export price of 4 tons of gas-fired boilers. Technical parameters of 4 ton gas-fired boiler:

Furnace Type: WNS4-1.25-Q

1. Rated steam output: 4T/h

2. Rated working pressure: 1.25 MPa

3. Feed water temperature: 20 ℃

4. Exit steam temperature: 194℃

5. Hydraulic test: 1.65 Mpa

6. boiler water capacity: 8.5m3

7. Exhaust Temperature (Gas): 51.27 ℃

8. boiler design efficiency (gas): 99.8%

9. Full-load operation gas consumption: 267.20 M3/h natural gas calorific value 9000 kcal/m3

10. Furnace radiation heating area: 21.068

11. Convective tube bundle heating area: 98.63

12. Condenser Heating Area: 78.38

13. Heating area of energy saver: 65.7

13. Initial Emission Concentration of Full-load Smoke and Dust: <50mg/m

14. boiler Installation Dimension: 5100 *2300 *3710mm

15. boiler Main Engine Transportation Weight: 14.5t

Know the technical parameters of 4 ton gas-fired boiler, also know the auxiliary equipment of the boiler:

Electric control cabinet: can choose the use of pressure, operation time, boiler water level, water temperature, outlet water temperature, steam temperature, etc., boiler start-up and shut-down automatically, burner automatic ignition, extinguishing.

Water pumps: industrial pumps, low noise, standard 2 pumps, one standby

Chimney: The inside diameter of the chimney is 27 cm and the height of the chimney is 8 M.

Softening water equipment: In order to prevent scaling of boilers and water pipes and affect the thermal efficiency and service life of boilers, softening water equipment is specially equipped to remove calcium and magnesium ions from water.

Condenser: also known as energy-saving device, using the flue gas at the end of the boiler to heat the inlet water temperature, not only improves the heat utilization rate of the boiler, but also reduces the exhaust temperature of the boiler flue gas. The gas temperature produced by our company can be as low as 91.9 degrees Celsius, which is far below the EIA data.

Dividing cylinder: The main steam from the boiler can be divided into different paths, and can be used for multiple steam demands at the same time.

Standard matching: one in three out.

Detailed export price of 4 tons of gas-fired boiler can be consulted online customer service.
