Home / gas fired boiler / SZS series gas-fired(oil-fired) steam boiler
01Outlet temperature:194-225 °C
02Product thermal capacity:10-50 t/h
03Working pressure:1.25-2.5 Mpa
Available industries:Heat suppling, chemical, food, textile, printing and dyeing, cigarettes and tobacco, fodder, pharmacy, building materials, brewery, rubber, hospital etc
Send Enquiry
Get Quotation(contact us by one of the three ways)
If you are interested in our products, please email us at [email protected]
SZS series boiler is designed with longitudinal double drums and " D " type chamber structure. Furnace is placed on the right and convection tube bank is on the left, super heater is arranged at convection tube bank. The body is fixed on the basement by middle and both end flexible supports and make the boiler expand horizontally sideways. Around the furnace is membrane water cooling tube wall. Furnace and tube bank are totally separated by the membrane water tube cooling wall at the left side of the furnace.
The back part of bundle is sparse shift structure, front part is aligned structure. Smoke from furnace outlet enters re-burning chamber,convection tube bank area and then from left front part enters spiral fine coil economizer and condenser, and finally is discharged to atmosphere through chimney.
1. By installing thermal insulation in the outlet of flue gas, we can reduce the boiler’s working noise. The furnace pressure is designed to be greater than 6000Pa.
2. The structural design focuses on details. The sealing of both sides of membrane wall and drums adopt comb plate. The boiler features a drainage system of condensation water in convection zone to prevent the corrosion of furnace body by acid condensate.
3. We adopts advanced automatic unionmelt welding process to ensure the welding quality. All the vertical and circular welding seams will be inspected by 100% X-ray detection.
4. The water circulation is enforced in the high temperature zone, which ensures efficient cooling in heating zone and prevent vaporization.
1, Program function modularization and efficient interlocking alarm function;
2, Automatic start and load PID automatic regulation function;
3, Fuel gas pressure abnormity fault interlock protection;
4, Automatic control function to water level (only for steam boiler);
5, Ultrahigh furnace temperature fault interlock protection (only for SZS boiler);
We are the boiler machinery manufacturer with nearly 36 year history. Both water tube boiler and fire tube boiler, we will provide it at China 100% factory price and maxmium discount for you. This series boiler body is designed with D-type chamber combustion structure. The membrane type structure is adopted for the circumference of the furnace body, the wall between the furnace and the convection zone, the front and rear walls of boilers body. The furnace pressure is designed to be greater than 6000Pa.
01
The furnace is on right side and the convection heating surface is on left side
02
Save you money and time with custom designed and engineered systems and solutions
03
he boilers are equipped with the safety valve, pressure gauge, water level gauge and safety interlocking
04
Membrane structure are used in the front and back wall for boiler body and highly increased their lifespan to over 20 years.
ZOZEN Boiler, which covers various types of fuels such as coal, fuel gas and biomass, produces high quality steam, hot water and organic carrier (heat transfer oil), which are widely used in chemical, pharmaceutical, food, feed, textile, building materials, Hotels, heating and other industries provide high-quality and reliable thermal power for industrial production and residents' lives.
